Product introduction:
●Voice prompt function.
●High quality temperature automatic adjustment function, to ensure the
actual temperature error within + / - 2 degrees.
●It is easy to operate and small in size. At present, it is one of the smaller
furnaces in the world.
●Precision stepper motor drive, smooth free operation and no jitter.
●High purity silicon carbide rod / silicon molybdenum rod heater.
●Hyperbolic sintering system, automatic temperature calibration before
each sinter process.
●Low noise tray and the speed is programmable.
●Fast sintering zirconia with full anatomical morphology.
●The pre-drying time can be set for baking zirconia denture.
●The maximum temperature can be set to 1550 ℃.
●The maximum heating rate is 200 C/min.
●There is no need to preheat the sintering furnace in advance. Ready to
use in any time.
●Automatic fast cooling technology.
●Up to 30-50 restorations (90mm tray) can be sintered.
●True color touch screen, easy to operate.
●50 custom programs and built-in programs.
●Status indication.
Product advantages：
OPERATION：
The velocity of temperature increasing: 200℃/min max.
The max temperature: : 1550℃ max
The time which can be kept at the max temperature: 2 H
ELECTRIC POWER：
Operation range：100-120V 50/60HZ 230V 50/60HZ Electric current：30ampere@110V 20ampere@230V Power：max 3000w
TYPICAL SPECIFICATION：
WXDXH :width 36cm Depth 46cm Height 59cm Usable measure (firing chamber):：9cm
Net weight：40Kg
Weight include the package:45Kg
AMBIENT CONDITIONS
Indoor use
Ambient temperature: 2°C to 40°C
Relative humidity 80% at 31°C
Maximum altitude: 1500 m (Special Model:3500m)
Rated voltage fluctuations must not exceed plus/minus 10% of the rated voltage
Actual shipping photos:
●Voice prompt function.
●High quality temperature automatic adjustment function, to ensure the
actual temperature error within + / - 2 degrees.
●It is easy to operate and small in size. At present, it is one of the smaller
furnaces in the world.
●Precision stepper motor drive, smooth free operation and no jitter.
●High purity silicon carbide rod / silicon molybdenum rod heater.
●Hyperbolic sintering system, automatic temperature calibration before
each sinter process.
●Low noise tray and the speed is programmable.
●Fast sintering zirconia with full anatomical morphology.
●The pre-drying time can be set for baking zirconia denture.
●The maximum temperature can be set to 1550 ℃.
●The maximum heating rate is 200 C/min.
●There is no need to preheat the sintering furnace in advance. Ready to
use in any time.
●Automatic fast cooling technology.
●Up to 30-50 restorations (90mm tray) can be sintered.
●True color touch screen, easy to operate.
●50 custom programs and built-in programs.
●Status indication.
Product advantages：
1.Maximum temperature set to 1550℃. Maximum heating rate of 200℃/min. 30-50 restorations (90mm tray) can be sintered at a time.
2.No preheating of the sintering furnace required. Ready to use immediately. Automatic rapid cooling technology.
3.Simple operation and compact size. Currently one of the smallest sintering furnaces in the world.
4.High-purity silicon carbide/molybdenum silicon rod heater. Rapid sintering to obtain zirconia with complete anatomical morphology.
5.Precision stepper motor drive for smooth, vibration-free operation. Low-noise tray with programmable speed.
6.True-color touchscreen for easy operation. Voice prompt function.
OPERATION：
The velocity of temperature increasing: 200℃/min max.
The max temperature: : 1550℃ max
The time which can be kept at the max temperature: 2 H
ELECTRIC POWER：
Operation range：100-120V 50/60HZ 230V 50/60HZ Electric current：30ampere@110V 20ampere@230V Power：max 3000w
TYPICAL SPECIFICATION：
WXDXH :width 36cm Depth 46cm Height 59cm Usable measure (firing chamber):：9cm
Net weight：40Kg
Weight include the package:45Kg
AMBIENT CONDITIONS
Indoor use
Ambient temperature: 2°C to 40°C
Relative humidity 80% at 31°C
Maximum altitude: 1500 m (Special Model:3500m)
Rated voltage fluctuations must not exceed plus/minus 10% of the rated voltage
Actual shipping photos:
