1700°Graphene vacuum furnace
1700°Graphene vacuum furnace

1700°Graphene vacuum furnace

Model:

Description:

Graphene vacuum furnace is widely used for heating treatment of metal materials in low vacuum, recursive, protective atmosphere, also can be used for heating treatment of special materials, such as carbonization process of carbon products.

Products
Detailed
Features:
1. Long-time Operation Temperature: 1700℃.
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient graphite felt insulation layer.
3. Lower temperature in outside case.
4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
5. Widely used in the heat treatment of metallic material in coarse vacuum, in reducibility or protective atmosphere.
1700° Graphene vacuum furnace

Description:
Model PT-V1700-3.4L
Structure Outside shell Carbon steel
Insulation layer Graphite Felt
Heating element Graphite
Chamber Size (mm) 150x150x150mm
Working Temperature  1600 ℃
Max. Temperature 1700 ℃
Temperature Accuracy +/-1 ℃
Thermocouple B-type
Temp. Control Yudian
30 steps programmable
PID automatic control
Vacuum Degree 10pa
Pressure rising rate ≤10-20pa/h
Vacuum pump Rotatory vane vacuum pump
Model: 2X-15
Speed: 15 L/s
Power: 1.5 Kw
Vacuum gauge High-accuracy Digital vacuum gauge
3.8x10-5 to 1125 Torr.
Brand: Inficon
Max. Power 15 Kw
Working Voltage AC440V, Three Phase, 60Hz
(or according to your requirement)
Accessories Crucible, gloves, crucible tong, Allen key, and so on.
Furnace Price 18000 USD
Transportation by sea 400 USD
Total C&F Price 18400 USD
Customization is available!
