Customized Mini Box Stove

Customized Mini Box Stove

Model:KJ-M600

Description:

KJ-M600 high temperature muffle furnace uses aludirome as heating element. Max. temperature inside furnace can be reached at 600℃ .

Detailed
KJ-M600 high temperature muffle furnace uses aludirome as heating element. Max. temperature inside furnace can be reached at 600℃ . The furnace temperature profile can be set up by 30 segments and run automatically by the 518P type advanced temperature controller. The furnace has no door, it is specially designed for small part heat treatment.Belongs to a type of muffle furnace.

Customized Mini Box Stove


Technical Specifications
Model KJ-M600
Display LED
Limiting Temperature 600℃
Usable Range ≤550℃
Heating Rate 0~20℃/min(suggest 0~10C/min)
Accuracy ±1℃(high temperature state)
Chamber size 90*20*180 mm(w*h*d)
Heating Element Resistance wire with Mo
Thermocouple K Type
Max. Power 0.5KW
Working Voltage AC 220V, single phase, 50 Hz
Temperature Control PID automatic control via SCR power control
Heating curves 30 steps programmable
Chamber material Alumina Fiber
Warranty One year limited warranty (Consumable parts such as heating elements are not covered by the warranty)


Customized Mini Box Stove
